Question 1

Where to find the exploded diagram for Short block on my Saab 900 1990?

Accepted Answer

Find on Saabiste.net the complete and official interactive technical diagram for Short block on Saab 900 1990. All components are detailed with their original SAAB OEM references.

Question 2

How do I identify a specific Saab reference in the section Short block?

Accepted Answer

Each part of the exploded diagram has a numbered marker linked to our parts table. You can click on the visual marker to instantly highlight the corresponding row containing the OEM part number, quantity, and chassis restrictions.

Question 3

How do I copy or use the part number of a component in section Short block?

Accepted Answer

Simply click on the monospace part number in the table. Saabiste will instantly copy the OEM part number to your clipboard to make it easier for you to search at your Saab parts suppliers.

Question 4

What does NLS mean in the Saab 900 catalog?

Accepted Answer

NLS stands for "No Longer Serviced". For these discontinued original parts in the section Short block, Saabiste displays, whenever available, the official replacement reference recommended by the manufacturer.

Question 5

Are the parts in this section Short block suitable for left-hand drive (LHD) or right-hand drive (RHD)?

Accepted Answer

Steering compatibilities are shown in the restrictions column of the parts table. You can also use the global EPC filters to hide part variants that are incompatible with your Saab's steering type (LHD/RHD).

Pos.	Part No.	Description	Usage	Qty
1	83 39 608 Engine pad	Engine pad		1
2	83 39 632 Cap	Cap		1
3	79 78 224 11 900 368 Screw	Screw		2
5	80 98 394 Screw	Screw		1
6	79 78 224 11 900 368 Screw	Screw		2
7	75 44 265 Bushing	Bushing		2
8	93 23 759 Engine anchorage LH	Engine anchorage	LH	1
9	93 24 930 Engine anchorage RH	Engine anchorage	RH	1
9	93 67 988 Engine anchorage B202I • RH	Engine anchorage	B202I RH	1
10	93 69 307 Engine pad LH	Engine pad	LH	1
10	75 43 408 Engine pad B202I • LH	Engine pad	B202I LH	1
11	93 69 315 Engine pad RH	Engine pad	RH	1
11	75 43 416 Engine pad B202I • RH	Engine pad	B202I RH	1
12	75 43 432 Screw	Screw		2
13	80 82 935 Screw	Screw		2
14	93 16 415 Screw	Screw		2
15	93 23 742 Engine anchorage	Engine anchorage		1
15	93 67 996 Engine anchorage B202I	Engine anchorage	B202I	1
16	79 79 131 Screw	Screw		2
17	81 51 243 Nut	Nut		2
18	83 56 859 Sleeve	Sleeve		2
19	80 83 941 Screw	Screw		2
20	75 49 579 Bracket	Bracket		1
21	75 32 161 Brace	Brace		1
22	81 51 235 Nut	Nut		4
23	80 29 985 92 153 033 Washer 1990-1992	Washer	1990-1992	4

Pos.	Part No.	Description	Usage	Qty
1	83 39 608 Engine pad	Engine pad		1
2	83 39 632 Cap	Cap		1
3	79 78 224 11 900 368 Screw	Screw		2
5	80 98 394 Screw	Screw		1
6	79 78 224 11 900 368 Screw	Screw		2
7	75 44 265 Bushing	Bushing		2
8	93 23 759 Engine anchorage LH	Engine anchorage	LH	1
9	93 24 930 Engine anchorage RH	Engine anchorage	RH	1
9	93 67 988 Engine anchorage B202I • RH	Engine anchorage	B202I RH	1
10	93 69 307 Engine pad LH	Engine pad	LH	1
10	75 43 408 Engine pad B202I • LH	Engine pad	B202I LH	1
11	93 69 315 Engine pad RH	Engine pad	RH	1
11	75 43 416 Engine pad B202I • RH	Engine pad	B202I RH	1
12	75 43 432 Screw	Screw		2
13	80 82 935 Screw	Screw		2
14	93 16 415 Screw	Screw		2
15	93 23 742 Engine anchorage	Engine anchorage		1
15	93 67 996 Engine anchorage B202I	Engine anchorage	B202I	1
16	79 79 131 Screw	Screw		2
17	81 51 243 Nut	Nut		2
18	83 56 859 Sleeve	Sleeve		2
19	80 83 941 Screw	Screw		2
20	75 49 579 Bracket	Bracket		1
21	75 32 161 Brace	Brace		1
22	81 51 235 Nut	Nut		4
23	80 29 985 92 153 033 Washer 1990-1992	Washer	1990-1992	4

110: Engine - Short block - Engine mounting
