Question 1

Where to find the exploded diagram for Intake and exhaust system on my Saab 900 1990?

Accepted Answer

Find on Saabiste.net the complete and official interactive technical diagram for Intake and exhaust system on Saab 900 1990. All components are detailed with their original SAAB OEM references.

Question 2

How do I identify a specific Saab reference in the section Intake and exhaust system?

Accepted Answer

Each part of the exploded diagram has a numbered marker linked to our parts table. You can click on the visual marker to instantly highlight the corresponding row containing the OEM part number, quantity, and chassis restrictions.

Question 3

How do I copy or use the part number of a component in section Intake and exhaust system?

Accepted Answer

Simply click on the monospace part number in the table. Saabiste will instantly copy the OEM part number to your clipboard to make it easier for you to search at your Saab parts suppliers.

Question 4

What does NLS mean in the Saab 900 catalog?

Accepted Answer

NLS stands for "No Longer Serviced". For these discontinued original parts in the section Intake and exhaust system, Saabiste displays, whenever available, the official replacement reference recommended by the manufacturer.

Question 5

Are the parts in this section Intake and exhaust system suitable for left-hand drive (LHD) or right-hand drive (RHD)?

Accepted Answer

Steering compatibilities are shown in the restrictions column of the parts table. You can also use the global EPC filters to hide part variants that are incompatible with your Saab's steering type (LHD/RHD).

Pos.	Part No.	Description	Usage	Qty
1	93 50 224 Exhaust gas recirculation valve -1990 • 02	Exhaust gas recirculation valve	-1990 02	1
1	88 59 977 Exhaust gas recirculation valve 1990- • 02	Exhaust gas recirculation valve	1990- 02	1
2	93 51 495 Nipple 02	Nipple	02	1
3	75 07 973 Gasket 02	Gasket	02	1
4	80 19 929 Screw 1990-1992 • 02	Screw	1990-1992 02	2
5	93 14 162 Valve 02	Valve	02	1
6	83 26 712 41 61 162 Seal 02	Seal	02	1
12	91 36 243 Vacuum hose 1990-1990 • 02 • L=170 MM \| Sold...	Vacuum hose	1990-1990 02 L=170 MM \| Sold...	1
13	91 36 243 Vacuum hose 02 • L=290 MM \| Sold...	Vacuum hose	02 L=290 MM \| Sold...	1
16	18 00 259 Tensioning band 1990-1990 • 02	Tensioning band	1990-1990 02	1
20	75 04 012 Tube 02	Tube	02	1
21	81 45 559 Nut 02	Nut	02	2
22	81 32 235 Ferrule 02	Ferrule	02	2
23	81 31 989 Nipple 02	Nipple	02	1
24	75 04 046 Protection 02	Protection	02	1
	91 36 243 Vacuum hose 02 • L=5000 MM \| Sold...	Vacuum hose	02 L=5000 MM \| Sold...	X

Pos.	Part No.	Description	Usage	Qty
1	93 50 224 Exhaust gas recirculation valve -1990 • 02	Exhaust gas recirculation valve	-1990 02	1
1	88 59 977 Exhaust gas recirculation valve 1990- • 02	Exhaust gas recirculation valve	1990- 02	1
2	93 51 495 Nipple 02	Nipple	02	1
3	75 07 973 Gasket 02	Gasket	02	1
4	80 19 929 Screw 1990-1992 • 02	Screw	1990-1992 02	2
5	93 14 162 Valve 02	Valve	02	1
6	83 26 712 41 61 162 Seal 02	Seal	02	1
12	91 36 243 Vacuum hose 1990-1990 • 02 • L=170 MM \| Sold...	Vacuum hose	1990-1990 02 L=170 MM \| Sold...	1
13	91 36 243 Vacuum hose 02 • L=290 MM \| Sold...	Vacuum hose	02 L=290 MM \| Sold...	1
16	18 00 259 Tensioning band 1990-1990 • 02	Tensioning band	1990-1990 02	1
20	75 04 012 Tube 02	Tube	02	1
21	81 45 559 Nut 02	Nut	02	2
22	81 32 235 Ferrule 02	Ferrule	02	2
23	81 31 989 Nipple 02	Nipple	02	1
24	75 04 046 Protection 02	Protection	02	1
	91 36 243 Vacuum hose 02 • L=5000 MM \| Sold...	Vacuum hose	02 L=5000 MM \| Sold...	X

1370: Engine - Intake and exhaust system - EGR system
