740: Engine - Fuel system - Filler pipe - Hose
(1990 - 1993) | For 900 (1990)
Also valid for CV 1994
100%
| Pos. | Part No. | Qty | |
|---|---|---|---|
| 1 | 89 82 209 43 91 058 Filler cap | 1 | |
| 2 | 75 11 751 Gasket | 1 | |
| 3 | 75 30 553 Filler pipe Without catalytic converter. | 1 | |
| 3 | 93 35 118 Filler pipe With catalytic converter. | 1 | |
| 4 | 75 36 840 Plastic plug ELCD | 1 | |
| 5 | 83 15 475 Stop | 2 | |
| 6 | 93 49 838 Gasket | 1 | |
| 7 | 83 23 941 Draining pipe | 1 | |
| 8 | 93 63 284 Hose L=52 MM | 1 | |
| 9 | 79 61 329 Bushing | 1 | |
| 10 | 89 82 498 Filler pipe -1991 | 1 | |
| 11 | 75 25 421 Hose | 1 | |
| 12 | 75 25 439 Hose -1990 | 1 | |
| 12 | 75 25 421 Hose 1990- | 1 | |
| 13 | 75 28 920 Hose | 1 | |
| 13 | 75 28 912 Hose | 1 | |
| 13 | 40 19 345 Cable | 1 | |
| 14 | 75 39 133 Hose | 1 | |
| 15 | 79 70 130 92 153 077 Hose clamp | 4 | |
| 16 | 40 18 354 Hose | 1 | |
| 17 | 83 32 587 Hose clamp | 2 | |
| 18 | 89 78 371 Nut | 4 | |
| 19 | 79 70 536 92 150 118 Screw | 4 | |
| 20 | 79 70 072 Hose clamp | 2 | |
| 21 | 79 68 308 Hose clamp | 4 | |
| 22 | 83 34 880 Hose | 1 | |
| 23 | 79 71 872 Tensioning band | 1 | |
| 24 | 75 39 976 Hose 3.314-3.328MM | 1 | |
| 24 | 93 63 243 Hose | 1 | |
| 25 | 93 18 361 Valve | 1 | |
| 26 | 79 22 347 Screw 1990-1990 | 2 | |
| 27 | 79 72 359 79 22 800 Screw | 2 | |
| 28 | 83 33 007 Protecting casing | 1 | |
| 30 | SEE SECTION FUEL TANK | ||
93 62 781 Hose L=10M | X |
