Pos.	Part No.	Description	Usage	Qty
1	75 86 019 Idle air control valve B202	Idle air control valve	B202	1
1	74 85 634 Control valve B202 • Cars with Lucas injection...	Control valve	B202 Cars with Lucas injection...	1
1	88 57 179 Control valve B212	Control valve	B212	1
2	75 69 056 Rubber ring B202	Rubber ring	B202	1
2	78 57 998 Rubber ring B212	Rubber ring	B212	1
3	74 80 916 Bracket	Bracket		1
4	81 25 023 Screw	Screw		1
5	93 50 653 Screw	Screw		2
6	80 29 951 Washer 1990-1992	Washer	1990-1992	2
7	91 28 505 Hose 1992-1993 • B202I, B202TURBO • With catalytic converter.	Hose	1992-1993 B202I, B202TURBO With catalytic converter.	1
7	91 28 497 Hose 1992-1993 • B212, B202S, B202TURBO	Hose	1992-1993 B212, B202S, B202TURBO	1
8	75 87 173 Hose B202	Hose	B202	1
8	75 87 181 Hose B212	Hose	B212	1
9	79 63 549 79 70 080 Hose clamp TURBO	Hose clamp	TURBO	2
9	79 63 531 79 70 072 Hose clamp Cars with Lucas injection...	Hose clamp	Cars with Lucas injection...	2
10	79 63 531 79 70 072 Hose clamp TURBO	Hose clamp	TURBO	1
11	79 63 523 79 70 064 Hose clamp TURBO	Hose clamp	TURBO	1

Pos.	Part No.	Description	Usage	Qty
1	75 86 019 Idle air control valve B202	Idle air control valve	B202	1
1	74 85 634 Control valve B202 • Cars with Lucas injection...	Control valve	B202 Cars with Lucas injection...	1
1	88 57 179 Control valve B212	Control valve	B212	1
2	75 69 056 Rubber ring B202	Rubber ring	B202	1
2	78 57 998 Rubber ring B212	Rubber ring	B212	1
3	74 80 916 Bracket	Bracket		1
4	81 25 023 Screw	Screw		1
5	93 50 653 Screw	Screw		2
6	80 29 951 Washer 1990-1992	Washer	1990-1992	2
7	91 28 505 Hose 1992-1993 • B202I, B202TURBO • With catalytic converter.	Hose	1992-1993 B202I, B202TURBO With catalytic converter.	1
7	91 28 497 Hose 1992-1993 • B212, B202S, B202TURBO	Hose	1992-1993 B212, B202S, B202TURBO	1
8	75 87 173 Hose B202	Hose	B202	1
8	75 87 181 Hose B212	Hose	B212	1
9	79 63 549 79 70 080 Hose clamp TURBO	Hose clamp	TURBO	2
9	79 63 531 79 70 072 Hose clamp Cars with Lucas injection...	Hose clamp	Cars with Lucas injection...	2
10	79 63 531 79 70 072 Hose clamp TURBO	Hose clamp	TURBO	1
11	79 63 523 79 70 064 Hose clamp TURBO	Hose clamp	TURBO	1

1250: Engine - Intake and exhaust system - Automatic idle speed control - Control
