3360: Electrical, connector - Contact housing etc - Engine

(1997 - 1998 | PETROL) | For 900 (1998)

100%

(N°3330)

Section 3360

(N°3390)

Pos.	Part No.	Description	Usage	Qty
11	44 32 316 12 790 262 Connector housing PETROL • 3-pin, female sensor camshaft	Connector housing	PETROL 3-pin, female sensor camshaft	1
11A	40 61 586 Cable terminal PETROL • AREA 1,0-2,5 MM2	Cable terminal	PETROL AREA 1,0-2,5 MM2	3
11B	40 61 974 12 798 372 Seal PETROL • AREA 2,1-2,9 MM2	Seal	PETROL AREA 2,1-2,9 MM2	3
12	41 78 414 12 790 247 Connector housing PETROL • 2-pin, female knock sensor	Connector housing	PETROL 2-pin, female knock sensor	1
12A	40 61 586 Cable terminal PETROL • AREA 1,0-2,5 MM2	Cable terminal	PETROL AREA 1,0-2,5 MM2	2
12B	40 61 974 12 798 372 Seal PETROL • AREA 2,1-2,9 MM2	Seal	PETROL AREA 2,1-2,9 MM2	2
13	41 13 601 12 788 993 Connector housing PETROL • 4-pin, female lambda sond	Connector housing	PETROL 4-pin, female lambda sond	1
13A	40 61 586 Cable terminal PETROL • AREA 1,0-2,5 MM2	Cable terminal	PETROL AREA 1,0-2,5 MM2	3
13B	40 61 974 12 798 372 Seal PETROL • AREA 2,1-2,9 MM2	Seal	PETROL AREA 2,1-2,9 MM2	3
14	41 13 205 12 788 933 Connector housing PETROL • 2-pin, female temperature sensor...	Connector housing	PETROL 2-pin, female temperature sensor...	1
14A	40 61 586 Cable terminal PETROL • AREA 1,0-2,5 MM2	Cable terminal	PETROL AREA 1,0-2,5 MM2	2
14B	40 61 974 12 798 372 Seal PETROL • AREA 2,1-2,9 MM2	Seal	PETROL AREA 2,1-2,9 MM2	2
15	41 78 414 12 790 247 Connector housing PETROL • 2-pin, female temperature sensor...	Connector housing	PETROL 2-pin, female temperature sensor...	1
15A	40 61 586 Cable terminal PETROL • AREA 1,0-2,5 MM2	Cable terminal	PETROL AREA 1,0-2,5 MM2	2
15B	40 61 974 12 798 372 Seal PETROL • AREA 2,1-2,9 MM2	Seal	PETROL AREA 2,1-2,9 MM2	2
16	41 78 414 12 790 247 Connector housing PETROL • 2-pin, female ignition coil	Connector housing	PETROL 2-pin, female ignition coil	1
16A	40 61 586 Cable terminal PETROL • AREA 1,0-2,5 MM2	Cable terminal	PETROL AREA 1,0-2,5 MM2	2
16B	40 61 974 12 798 372 Seal PETROL • AREA 2,1-2,9 MM2	Seal	PETROL AREA 2,1-2,9 MM2	2
17	44 09 801 Cable terminal PETROL • AREA 0,5-1,0 MM2 \|...	Cable terminal	PETROL AREA 0,5-1,0 MM2 \|...	1
