Question 1

Where to find the exploded diagram for Contact housing etc on my Saab 900 1998?

Accepted Answer

Find on Saabiste.net the complete and official interactive technical diagram for Contact housing etc on Saab 900 1998. All components are detailed with their original SAAB OEM references.

Question 2

How do I identify a specific Saab reference in the section Contact housing etc?

Accepted Answer

Each part of the exploded diagram has a numbered marker linked to our parts table. You can click on the visual marker to instantly highlight the corresponding row containing the OEM part number, quantity, and chassis restrictions.

Question 3

How do I copy or use the part number of a component in section Contact housing etc?

Accepted Answer

Simply click on the monospace part number in the table. Saabiste will instantly copy the OEM part number to your clipboard to make it easier for you to search at your Saab parts suppliers.

Question 4

What does NLS mean in the Saab 900 catalog?

Accepted Answer

NLS stands for "No Longer Serviced". For these discontinued original parts in the section Contact housing etc, Saabiste displays, whenever available, the official replacement reference recommended by the manufacturer.

Question 5

Are the parts in this section Contact housing etc suitable for left-hand drive (LHD) or right-hand drive (RHD)?

Accepted Answer

Steering compatibilities are shown in the restrictions column of the parts table. You can also use the global EPC filters to hide part variants that are incompatible with your Saab's steering type (LHD/RHD).

Pos.	Part No.	Description	Usage	Qty
20	46 68 810 Connector housing 29 • 24-pin, female connection	Connector housing	29 24-pin, female connection	1
20A	43 50 526 Cable terminal 29 • AREA 0,5-1,0 MM2	Cable terminal	29 AREA 0,5-1,0 MM2	3
20A	40 61 586 Cable terminal 29 • AREA 1,0-2,5 MM2	Cable terminal	29 AREA 1,0-2,5 MM2	13
20B	46 92 851 Locking 29	Locking	29	1
21	46 68 869 Connector housing 29 • 24-pin, male connection	Connector housing	29 24-pin, male connection	1
21A	43 50 609 Cable terminal 29 • AREA 0,5-1,0 MM2	Cable terminal	29 AREA 0,5-1,0 MM2	3
21A	41 15 192 12 789 934 Cable terminal 29 • AREA 1,0-2,5 MM2	Cable terminal	29 AREA 1,0-2,5 MM2	13
21B	46 92 851 Locking 29	Locking	29	1

Pos.	Part No.	Description	Usage	Qty
20	46 68 810 Connector housing 29 • 24-pin, female connection	Connector housing	29 24-pin, female connection	1
20A	43 50 526 Cable terminal 29 • AREA 0,5-1,0 MM2	Cable terminal	29 AREA 0,5-1,0 MM2	3
20A	40 61 586 Cable terminal 29 • AREA 1,0-2,5 MM2	Cable terminal	29 AREA 1,0-2,5 MM2	13
20B	46 92 851 Locking 29	Locking	29	1
21	46 68 869 Connector housing 29 • 24-pin, male connection	Connector housing	29 24-pin, male connection	1
21A	43 50 609 Cable terminal 29 • AREA 0,5-1,0 MM2	Cable terminal	29 AREA 0,5-1,0 MM2	3
21A	41 15 192 12 789 934 Cable terminal 29 • AREA 1,0-2,5 MM2	Cable terminal	29 AREA 1,0-2,5 MM2	13
21B	46 92 851 Locking 29	Locking	29	1

3510: Electrical, connector - Contact housing etc - Engine
